CL-018-NF | Times Microwave Systems
Calculator LMR Cables
Product Finder

CL-018-NF

Type N, female (jack), straight, CL style connector for CLS18 and CLU18 type cables.

CL-018-NF

Stock Code: 3190-6904

Type N Female

Request a Quote

Specifications

Part NumberCL-018-NF
Stock Code3190-6904
InterfaceN
Gender Female (jack)
Orientation Straight
PIM RatingN/A
Impedance (ohms)50
Max Frequency (GHz)18
VSWR Freq1.20:1
VSWR Frequency (GHz)18
Coupling NutN/A
Inner Contact AttachSolder
Outer Contact AttachSolder
Body FinishPassivated
Pin FinishGold
Length (mm)
Length (in)
Width (mm)
Width (in)
Weight (g)41
Weight (lb)0.09

Compatible with

Clarity 18 ArmoredClarity 18 Unarmored
