TCOM-400-FS-DB
TCOM®-400-FS-DB is a rugged, low-loss coaxial cable with the same attenuation as LMR®, designed for low PIM performance and flexibility. It features a stranded center conductor and a watertight, UV-resistant black polyurethane jacket, making it ideal for outdoor and harsh environments requiring movement after installation and long-term durability.
Stock Code: 55019
TCOM-400 cable/stranded center conductor,black PU jacket,watertight
Inventory Status
| Distributor | Qty | Order |
| CDM Inc. | 62 | Buy |
Specifications
| Part NumberTCOM-400-FS-DB |
| EnvironmentIndoor |
| JacketPUR |
| Overall Diameter (mm)10.287 |
| Overall Diameter (in)0.405 |
| Weight Kg/m0.08 |
| Weight lb/ft0.08 |
| Operating Temp.°C (°F)
-40° to 85°C
(-40° to 185°F) |
| Min. Bend Radius (mm)25.4 |
| Min. Bend Radius (in)1 |
| Bending Moment (Nm)0.68 |
| Bending Moment (ft-lb)0.5 |
| Max Frequency (GHz)6 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
Part Number Structure
Cable Details
