SiO2-200
SiO2-200 semi-rigid cable assembly is built for exceptional phase stability and low insertion loss in extreme environments. Designed for aerospace, defense, and satellite systems, it features a rugged SiO2 dielectric and robust construction. SiO2-200 delivers consistent, high-frequency performance under harsh thermal, vibration, and radiation conditions, making it ideal for precision RF and microwave applications.
Stock Code: AA-9791
SiO2-200
Request a Quote
Specifications
| Part NumberSiO2-200 |
| Environment |
| Jacket304L SS |
| Overall Diameter (mm)5.1308 |
| Overall Diameter (in)0.202 |
| Weight Kg/m0.6548 |
| Weight lb/ft0.44 |
| Operating Temp.°C (°F)-270° to 1000°C (-454° to 1832°F) |
| Min. Bend Radius (mm)20.32 |
| Min. Bend Radius (in)0.8 |
| Bending Moment (Nm) |
| Bending Moment (ft-lb) |
| Max Frequency (GHz)25 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
Compatible with
Part Number Structure
Cable Details
