QEAM-810
The QEAM-810 is a high-performance RF cable assembly designed for mission-critical defense applications requiring repeated reeling and unreeling. With proven reliability on platforms like the Hawk and Patriot Missile systems, it withstands wide temperature extremes and harsh conditions. Its robust design and flame-retardant jacket ensure long-term durability in tactical environments demanding top-tier signal performance.
Stock Code: AA-8848
QEAM-810 Quick Erecting Antenna Mast High Performance RF Cable
Request a Quote
Specifications
| Part NumberQEAM-810 |
| Environment |
| JacketFlame Retardant Polyurethane |
| Overall Diameter (mm)20.574 |
| Overall Diameter (in)0.81 |
| Weight Kg/m0.5953 |
| Weight lb/ft0.4 |
| Operating Temp.°C (°F)-55° to 200°C (-67° to 392°F) |
| Min. Bend Radius (mm)203.2 |
| Min. Bend Radius (in)8 |
| Bending Moment (Nm) |
| Bending Moment (ft-lb)6 |
| Max Frequency (GHz)5 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
