PTSRB-086
The PhaseTrack®-86 is a Semi-Rigid phase-stable coax assembly featuring a proprietary fluorocarbon dielectric, TF4®, eliminating the PTFE change phase occurring around 19 ºC. The PhaseTrack Semi-Rigid cable assemblies are perfect for in-the-box or extreme environment applications where stable phase over temperature is necessary.
Stock Code: AA-11318T
PTSRB-086
Build your Assembly
This a factory assembled custom assembly. The cable and connectors are not available for individual sale.
Specifications
| Part NumberPTSRB-086 |
| Environment |
| JacketCopper |
| Overall Diameter (mm)2.2098 |
| Overall Diameter (in)0.087 |
| Weight Kg/m0.013 |
| Weight lb/ft0.013 |
| Operating Temp.°C (°F)
-55° to 125°C
(-67° to 257°F) |
| Min. Bend Radius (mm) |
| Min. Bend Radius (in)0.35 |
| Bending Moment (Nm) |
| Bending Moment (ft-lb) |
| Max Frequency (GHz)80.2 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
Part Number Structure
Cable Details
