PTLS-200
The PhaseTrack®200 is a Low-Smoke Zero-Halogen phase-stable coax assembly featuring a proprietary fluorocarbon dielectric, TF4®, eliminating the PTFE change phase occurring around 19 ºC. PhaseTrack assemblies have the same triple-shield construction used in our popular SF®, SFT®, SilverLine®, and MilTtech® cables and are ideal for shipboard and other MIL-DTL-17 applications demanding stable phase over temperature.
Stock Code: AA-9525
PTLS-200
Build your Assembly
This a factory assembled custom assembly. The cable and connectors are not available for individual sale.
Specifications
| Part NumberPTLS-200 |
| Environment |
| JacketLow Tox Polyolefin |
| Overall Diameter (mm)0.2 |
| Overall Diameter (in)0.2 |
| Weight Kg/m0.0336 |
| Weight lb/ft0.0336 |
| Operating Temp.°C (°F)85° to 85°C (-40° to 185°F) |
| Min. Bend Radius (mm)25.4 |
| Min. Bend Radius (in)1 |
| Bending Moment (Nm)0.27134142 |
| Bending Moment (ft-lb)0.2 |
| Max Frequency (GHz)38 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
Part Number Structure
Cable Details
Documentation
