MG-160-LSLT
MaxGain® 160-LSLT is a lightweight, ultra-low-loss coaxial cable designed for high-frequency performance in environments requiring low smoke and low toxicity. Its spiral outer conductor ensures excellent shielding, flexibility, and signal stability, making it an ideal choice for aerospace, defense, and other demanding microwave interconnect systems.
Stock Code: AA-11445
MaxGain-160-LSTS Low-Smoke, low-loss, high performance microwave coaxial cable
Build your Assembly
This a factory assembled custom assembly. The cable and connectors are not available for individual sale.
Specifications
| Part NumberMG-160-LSLT |
| Environment |
| JacketLow Toxicty Polyolefin |
| Overall Diameter (mm)4.953 |
| Overall Diameter (in)0.195 |
| Weight Kg/m0.0476 |
| Weight lb/ft0.032 |
| Operating Temp.°C (°F)-30° to 85°C (-22° to 185°F) |
| Min. Bend Radius (mm)28.956 |
| Min. Bend Radius (in)1.14 |
| Bending Moment (Nm) |
| Bending Moment (ft-lb) |
| Max Frequency (GHz)40 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
Part Number Structure
