LMR®-400-FR 50 Ohm coax cable features a non-halogen, low smoke, fire-retardant jacket, ideal for indoor RF use. It meets UL/NEC CMR, CSA FT4, FAA FAR25, and MSHA-P standards, making it a reliable, high-performance cable for building runs and mining applications, excluding air handling plenums,
LMR-400 w/non-halogen FR jkt, listed CMR/MPR (PCC-FT4)
| Part NumberLMR-400-FR |
| EnvironmentIndoor |
| JacketFR-PE |
| Overall Diameter (mm)10.287 |
| Overall Diameter (in)0.405 |
| Weight Kg/m0.131 |
| Weight lb/ft0.088 |
| Operating Temp.°C (°F)
-40° to 85°C
(-40° to 185°F) |
| Min. Bend Radius (mm)25.4 |
| Min. Bend Radius (in)1 |
| Bending Moment (Nm)0.68 |
| Bending Moment (ft-lb)0.5 |
| Max Frequency (GHz)6 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
