IB-141

InstaBend® -141 is a flexible, coaxial microwave assemblies designed for interconnects between RF circuit cards, modules and enclosure panels. The cable can be bent very closely behind the connector, simplifying cable routing. 141

Stock Code: 510-0201

InstaBend 141 cable

Inventory Status
In Stock Qty Order

Specifications

Part NumberIB-141
EnvironmentIndoor
JacketFEP
Overall Diameter (mm)4.14
Overall Diameter (in)0.163
Weight Kg/m0.061
Weight lb/ft0.028
Operating Temp.°C (°F)-65° to 125°C (-85° to 257°F)
Min. Bend Radius (mm)12.7
Min. Bend Radius (in)0.5
Bending Moment (Nm)
Bending Moment (ft-lb)
Max Frequency (GHz)32
Impedance (ohms)50
Power Handling (DWV)

Compatible with

Can't find what you're looking for?

Part Number Structure

Part number structure

Cable Details

Cable details
