IB-086
InstaBend® -086 cable is a flexible, coaxial microwave assembly designed for interconnects between RF circuit cards, modules and enclosure panels. The cable can be bent very closely behind the connector, simplifying cable routing.
Stock Code: AA-12025
InstaBend 086 cable
Inventory Status
| Distributor | Qty | Order |
Specifications
| Part NumberIB-086 |
| EnvironmentIndoor |
| JacketFEP |
| Overall Diameter (mm)2.743 |
| Overall Diameter (in)0.108 |
| Weight Kg/m0.013 |
| Weight lb/ft0.013 |
| Operating Temp.°C (°F)
-65° to 125°C
(-85° to 257°F) |
| Min. Bend Radius (mm)6.35 |
| Min. Bend Radius (in)0.25 |
| Bending Moment (Nm) |
| Bending Moment (ft-lb) |
| Max Frequency (GHz)50 |
| Impedance (ohms)50 |
| Power Handling (DWV) |
